Specifications | ||
Display interface | VGA,HDMI | |
Shell Material | Aluminum, SGCC | |
Size | 536.2 x 329.4 x 51 mm | |
Weight | 5.8 KG | |
Power input | 12V /3A | |
Support System | Windows® 7/8/10, WES 7, Linux | |
OSD menu | Adjustable screen brightness, contrast, support one-key adjustment to the best state | |
Installation method | Panel Mount, Wall Mount, Desktop Mount, VESA75 Cantilever Mount | |
Display | ||
LCD Type | TFT-LCD | |
Resolution | 1920 x 1080 | |
Max Color | 16.7M | |
Brightness | 300 cd/m² | |
Perspective(CR>=10) | -89~89° (H), -89~89° (V) | |
Backlight | LED | |
Backlight Lifetime (hours) | 50,000 | |
Contrast | 1000:1 | |
Touch screen | ||
Type | Five-wire resistive | 10 point capacitive screen |
Interface Type | USB2.0 | USB2.0 |
Transmittance | 85% | greater than85% |
Lifetime | 250g force 10 million clicks | Hardness 7H |
Use environment | ||
Operating temperature | -10℃ ~ 60℃ | |
Storage temperature | -20°C ~ 70°C | |
Storage humidity | 10~90% @30°C, no condensation | |
Protection Level | Front panel IP65 | |
Vibration resistance | 5~500 Hz, 1Grms (operating,ramdom) | |
