Specifications | ||
Display interface | VGA,HDMI | |
Shell Material | Aluminum, SGCC | |
Size | 230.3 x 177.3 x 41.4 mm | |
Weight | 1.42 KG | |
Power input | 12V /3A | |
Support System | Windows® 7/8/10, WES 7, Linux | |
OSD menu | Adjustable screen brightness, contrast, support one-key adjustment to the best state | |
Installation method | Panel Mount, Wall Mount, Desktop Mount, VESA75 Cantilever Mount | |
Display | ||
LCD Type | TFT-LCD | |
Resolution | 800 x 600 (optional 1024 x 768) | |
Max Color | 16.7M | |
Brightness | 250 cd/m² | |
Perspective(CR>=10) | -70~70° (H), -50~70° (V) | |
Backlight | LED | |
Backlight Lifetime (hours) | 20,000 | |
Contrast | 500:1 | |
Touch screen | ||
Type | Five-wire resistive | 10 point capacitive screen |
Interface Type | USB2.0 | USB2.0 |
Transmittance | 85% | greater than85% |
Lifetime | 250g force 10 million clicks | Hardness 7H |
Use environment | ||
Operating temperature | -20℃ ~ 70℃ | |
Storage temperature | -30°C ~ 80°C | |
Storage humidity | 10~90% @30°C, no condensation | |
Protection Level | Front panel IP65 | |
Vibration resistance | 5~500 Hz, 1Grms (operating,ramdom) | |
